Selective absorption colored filter glass->Green glass

Green glass Characteristic
Type Thickness
(mm)
A[2856k] D65 Chemical Stability ND α×10-7
(℃)
Tg
(℃)
Ts
(℃)
S
x y Y x y Y DA DW
LB1 2 0.328 0.593 24.6 0.268 0.586 28.2 1 3 1.524 96 535 599 2.52
LB2
2 0.250 0.669 9.7 0.216 0.658 11.9 1 2 1.524 96 535 599 2.52
LB3 2 0.252 0.502 23.7 0.196 0.374 29.3 1 1 1.523 98 526 597 2.52
LB4
2 0.230 0.516 16.3 0.183 0.387 20.7 1 1 1.523 89 525 598 2.52
LB6 2 0.426 0.468 71.9 0.320 0.424 73.6 6 5 1.534 100 421 463 2.83
LB7 2 0.360 0.603 25.6 0.308 0.629 28.4 1 2 1.547 104 458 526 2.85
LB8 2 0.496 0.459 34.9 0.420 0.475 32.3 1 2 1.523       2.52
LB9 2 0.462 0.452 86.7 0.353 0.429 85.2 1 2 1.547 104 458 526 2.85
LB10 2 0.472 0.477 79.2 0.383 0.495 77.6 1 3 1.547 104 458 526 2.85
Technical Indexes
Type Thickness
(mm)
430
(nm)
450
(nm)
520
(nm)
530
(nm)
650
(nm)
LB1 2 ≤0.4     ≥41.9 ≤3.2
LB2 2   ≤0.2   ≥18.3 ≤0.2
LB3 2   15.2~29.0 ≥40.0   ≤1.7
LB4
2   6.0~15.9 ≥24.1   ≤0.2
Type Thickness
(mm)
400
(nm)
420
(nm)
460
(nm)
480
(nm)
550
(nm)
560
(nm)
620
(nm)
650
(nm)
660
(nm)
LB6 2     41.7~50.1     ≥79.4     25.1~33.1
LB7 2         545
32.0-45.0
  ≤8.0
LB8 2   ≤1.3       30.3~43.9   640
25.2-40.0

LB9 2 ≤2.0       ≥82.0     65.0~70.0
LB10 2   ≤1.0     ≥72.0     50.0~60.0
Class Of Bubble、Stripe、Stress
Type Bubble Stripe Stress
LB1 C-B 4 3
LB2
C-B 4 3
LB3 C-B 4 3
LB4
C-B 4 3
LB6 C 3C 4
LB7 C-B 3C 3
LB8 C-B 3C 3
LB9 C-B 3C 3
LB10 C-B 3C 3
Green glass Green glass
